NU3044-M1-R160-240 FAG

The NU3044-M1-R160-240 FAG is a single-row cylindrical roller bearing with cage. This bearing consists of a solid inner and outer ring with cylindrical rollers in a cage. This cage prevents contact between the cylinder rollers, so this bearing type can support higher speeds than full-complement cylinder roller bearings. Also, single-row cylindrical roller bearings with cages are very rigid and they can take high radial forces. As the inner and outer rings of these bearings can be easily disassembled, they are very easy to install. Applications of single-row cylindrical roller bearings include gearboxes, agricultural machinery, pumps, compressors, and electric motors. The NU3044-M1-R160-240 FAG is a single-row cylindrical bearing with NU design. The outer ring of this bearing has two rigid ribs, while the inner ring has none. As a result, NU bearings are only capable of supporting radial forces. This bearing type is commonly used as a floating bearing. Floating bearings allow axial displacement of the shaft relative to the housing in both directions. This is necessary in applications where the shaft material shrinks or expands due to temperature changes (thermal expansion). NU bearings can also be used as support bearings by combining them with HJ angle rings (available separately). Support bearings can support radial forces and also axial forces in a single direction.

Category：

Cylindrical Roller Bearings

FAG

+86-18301921252

shbq@bqskfbearing.com

E-mail

Related Products

Message

Product features:

Radial cyindricalroller bearing is separable bearing and can be used to locate not bearing,half bearing positioning, or locating bearingCharacteristic is able to function under load in both directions Jose, have relatively high rated speed.The internal structure of the cylindrical roller bearing adopts rollers arranged in parallel, and the rollers are equipped with spacing retainers or isolation blocks, which can prevent the inclination of rollers or mutual friction between rollers, and effectively prevent the increase of rotating torque.

Packaging and delivery

It has grown steadily in the market competition and established a good reputation and credibility in the industry. In the future, Shanghai Baiqi Bearing will continue to uphold the concept of "honest management and excellence", continue to innovate and develop, and create greater value for customers.

Inspection

The company has advanced production equipment and technical teams. Its products cover various types of rolling bearings, deep groove ball bearings, tapered roller bearings and other series, which are widely used in mechanical equipment, automotive industry, aerospace and other fields.

FAQ

Q: What are your payment terms?

A: Payment <= 1000 USD, 100% USD in advance. Payment > = $1000, 30% T/T in advance, balance before delivery.

Q: Do you provide samples? Is it free or extra?

A: Yes, we can provide samples free of charge, but we don't pay for shipping.

Q: What is your lead time?

A: If the goods are in stock, it is usually 5-10 days. Or, if the goods are not in stock, then 15-20 days, it is based on quantity.

Q: Are you a trading company or a manufacturer?

A: We are a factory!
